New 380 Realm Hull 2024 Model

4x Mercury V8 300 Verado Engines in Black

Priced from:  £ P.O.A.

Let the adventures begin: Introducing the newest member of Boston Whaler’s exciting Realm family, the versatile 380 Realm. Combining incredible capability and performance with outstanding comfort, the 380 Realm is designed to make any on-water dream possible. Amenities for entertaining include a robust cockpit prep center; a massive, refrigerated under-seat cooler; a social open bow and more. The boat’s spacious center-console layout and brilliant new windshield design provide unobstructed views, while a large integrated hardtop provides tons of shade and protection from the elements — all the way to the horizon and beyond.

  • 450-gallon fuel tank for impressive range.
  • Convenient cockpit prep center includes grill and fridge, or optional livewell.
  • Massive under-seat cockpit storage holds days’ worth of chilled beverages.
  • Nested wind-break door in full windshield provides protection as well as easy bow access.
  • Options including a bow sunshade, table and sun pad filler cushion increase the bow’s versatility.
  • Advanced Seakeeper® gyro-stabilization technology available.
  • Huge, state-of-the-art helm station accommodates three display screens.
  • Easy access via starboard boarding steps.
  • Cabin features fully enclosed head with shower, galley, entertainment center and convertible V-berth for overnight stays.
  • Variable running surface hull ensures a smooth ride for long-distance journeys and all-day cruising.





  • LOA: 38’ (11.89 m)
  • Beam: 11’ 8” (3.56 m)
  • Draft: 29“(0.74 m)
  • Weight (dry, no engine): 15,500 lbs. (7030.7 kg)
  • Weight (base boat, std. engines): 18,300 lbs. (8,301 kg)
  • Weight (base boat, std. engines, fuel and water): 21,415 lbs. (9,714 kg)
  •  Max. Weight Capacity: 4,500 lbs. (2,041.2 kg)
  • Swamp Capacity: 3,500 lbs. (1,587.6 kg)
  • Maximum Persons Capacity: 16
  • Maximum HP: 1600 hp (1176.6 kW)
  •  Minimum HP: 1200 hp (882.5 kW)
  •  Maximum Engine Weight: 2,800 lbs. (1,270.1 kg)
  •  Transom Height: 30” (0.76 m)
  •  Transom Angle: 15º
  •  Dead rise at Transom: 23º
  •  Fuel Capacity: 450 gallons (1,703.4 L)
  • Waste Capacity: 10 gallons (37.85 L)
  • Water Capacity: 60 gallons (227.1 L)
  •  Bridge Clearance with Top: 9’ 0” (2.74m)
  •  Bridge Clearance with Top and Radar: 10’ 3” (3.12m)

All hardware 316-L stainless steel
All rails welded 316-L stainless steel

10” stainless steel cleats – stern cockpit with gunnel board hawse pipe (2), anchor locker (1)
10” stainless steel pull-up cleats – bow (2), midship spring line (2), crosstie cleats at transom (2)
28” interior freeboard
Acrylic transom door with stainless steel latch
Bow eye
Drink holders (stainless steel) – bow (9), helm(4), prep station (3), second row seating (3), forward console lounge (3), cockpit gunnel boards (2)
Full coaming bolsters
Integral swim platform with recessed telescoping dive ladder and grab rail
Lighting – blue and white LED courtesy lighting (cockpit)
Lighting – machinery space LED lighting
Molded fiberglass port side dive/boarding door with removable stainless steel dive ladder
Rails – bow rail (low profile interior)(welded stainless steel)
Rails – grab rails (stainless steel)
Rails – heavy duty stainless steel rub rail
Rod holders (gunnel mounted) – starboard cockpit (2), port cockpit (2)
Rod holders (transom)(3)
Self-bailing cockpit sole
Thru hull anchor roller davit (stainless steel)
Windlass – 400’ of rode and chain with handheld remote control, stainless steel swivel, galvanized steel anchor (35 lbs) and polished stainless steel bow roller

Dash visor with custom stitched cover and recessed storage tray with 1 dual USB and 12-V charging receptacle
Drink holders (3)
Electronics mounting surface with space for triple displays
Electrical system switch panel with illuminated text
Ignition switches – remote key switches in main DC panel cabinet with pushbutton start/stop at helm
Lockable acrylic sliding cabin entry door
Lockable glovebox with 12-V receptacle and dual USB charging port
Mercury® DTS dual binnacle controls featuring Shadow Mode for center engine with integrated engine trim controls
Mercury® SmartCraft Vessel View Display 7” color LCD display (network connections to Raymarine with Navigation Package)
Molded console footrests and fold-down helm standing platform with maintenance free, anti-fatigue synthetic surface providing improved visibility and comfort for the captain
Steering wheel (cast stainless steel with urethane grip, speed knob and tilt)
Stereo – Fusion® MS-BB300 (integrated into Raymarine with navigation package)
– includes: Fusion stereo, AM/FM/VHF/ MP3, USB Aux input, iPod/iPhone/Android compatible via integrated Bluetooth, Sirius XM option ready, stereo remote controls with LCD display providing full audio control from the cabin, helm and bow JL Audio waterproof speakers (exterior, 7.7” aft cockpit (2), 7.7” (component with Hardtop Tweeter), 7.7” coax and helm deck (4), 7.7” coax at bow (2), 10” sub-woofer at helm deck (1), 8” sub-woofer at bow (1), 6.5” coax in cabin (2) with JL Audio amplifiers)

Foldout stern bench seat with elevated backrest
Bow lounge with backrest and fold-down armrests with drink holders (5)
Bow wrap-around seating with drink holders (4), full height forward bolster and removable cushions
Deluxe port side helm deck seat with armrests (adjustable slide and swivel enabling rotation of the seat inboard)
Deluxe swivel 2-person helm seat with armrests (adjustable electric slide and 180-degree rotation creating an apposed seating conversation and dining area)
Helm deck second row with 2-person seat with a conversation seatback transforming to an aft facing seat with flip-down teak foot rests

Bow anchor locker with drains and LED lighting
Cabin – starboard side storage cabinet with shelves
Cabin – port side cedar-lined storage cabinet
Cabin – port side compartment under settee
Canvas enclosure or lifejacket storage in hardtop
Electronics box in hardtop
Forward coaming pockets
Glovebox at helm
Head storage compartment
Insulated 260qt built-in cooler/storage under second row seating with dual access
Insulated 70qt cooler/storage in port side bow gunnel
Insulated in-floor fishboxes with pump-out – aft (2)
Prep station drawer with 5-gallon bucket/trash receptacle
Prep station drawer storage
Second row seating port side pocket and starboard pull-out grilling accessory storage
Storage compartments (midship in coaming)
Storage compartment (transom mounted tilt out)
Storage under bow seat with LED lighting (3 compartments with remote latch release)

Canvas enclosure or life jacket storage
Hardtop frame – custom powder-coated aluminum frame integrated into the deck providing unobstructed walkways
Hardtop hatches (opening) – integrated into the hardtop
Ladder access to hardtop
Lighting (flood light) – recessed LED lighting for bow area (2)
Lighting (flood lights) – recessed LED lighting for cockpit area (2)
Lighting – red/white LED courtesy map light (1)
Lighting – blue/white LED overhead courtesy lighting (6)
Lighting – LED navigation lights recessed in the hardtop
Lockable electronics box
Outrigger ready
Tempered side glass and windshield with power actuated vent, opening walk-through windshield with separate lower door providing weather protection
Windshield defogger system (integrated into the hardtop)
Windshield wiper – dual pantograph with wash system and intermittent/multi-speed control

120V GFI outlet
Corian countertop
Deluxe port side helm seat deck seat with armrests, adjustable slide and swivel enabling rotation of the seat inboard
Drink holders (3)
Electric grill with solid surface cover with custom popup rotation providing a prep counter while grilling Freshwater sink with recessed cutting board cover and fold away polished faucet with hot and cold water
Grab rail – stainless steel
Refrigerator – stainless steel (12V/120V)(2.3 cubic ft.)
Storage compartment built into solid surface behind the grill
Storage drawer with 5-gallon bucket/trash receptacle
Storage drawers

120V receptacle (port side)
12V receptacle (port side)
24” flat screen HDTV (with Apple TV)
Cabinetry – natural teak wood with satin finish
Carbon monoxide detector
Central vacuum system with hose and attachments with dedicated storage
Digital Vessel Control and Information – iPad with inductive wireless charging case (custom app to wirelessly monitor and control some vessel systems and DC circuits)
Easy to clean interior materials
Hardwood cabin sole
Lighting – LED white overhead lights with dimmer switches (6)
Lighting – LED blue/white diffused courtesy lighting with dimmer switch
Lockable acrylic cabin door
Opening portholes (1)
Opposing seating that converts to berth with included fitted sheets
Portside window with pull-down blind
Refrigerator – stainless steel (12V/120V)(1.7 cubic feet)
Sink – molded fiberglass sink with hot and cold polished faucet
Sink filler – solid surface matching countertop with integral cutting board on back side
Skylight with removable shade
Storage compartment under port settee
Table – solid teak with high gloss finish on a high low pedestal
USB power receptacle – dual inputs (port and starboard)

120V outlet
750 GPH shower sump
Accent wall
Flooring – solid surface tile
Full length mirror mounted on door
Lighting – LED overhead
Pullout showerhead with mixer valve and vertical adjustment
Shower curtain
Sink – vessel sink with hot and cold faucet
Solid surface vanity countertop
Storage cabinet
Toilet paper holder
VacuFlush™ toilet, holding tank, dockside pump-out, overboard discharge and tank level indicator
Vanity grab rail
Ventilation fan

300L6 DTS Quad Black Mercury Verado FourStroke engines with hydraulic power steering and Shadow Mode technology (91 octane fuel recommended)
450-gallon aluminum fuel tank
Advanced battery management system (electric switches with pushbutton paralleling)
Air conditioner (cabin)(12,000 BTU, reverse cycle)
Air conditioner (cockpit)(18,000 BTU, reverse cycle)
Battery charger (50 AMP at 12V multi-stage charger)
Battery system – includes: battery trays, remote switches, automatic charging/paralleling relays
Bilge pump – high water pump with alarm (2000 GPH)
Bilge pump – automatic (1100 GPH fwd, 2000 GPH aft)
Bonding system for underwater through hull fittings
Bow thruster (4kW)(not available with Joystick Piloting engine options)

Cast bronze thru hulls, seacocks and sea strainers (below waterline)
Cast stainless steel thru hulls (above waterline)
Electric dual polished stainless steel trumpet horns
Electric trim tabs with indicator (Auto Glide, Dynamic Running Surface, dual ram)
Engine fuel / water separators
Freshwater dockside hookup and tank level indicator integrated into Vessel View for hot and cold pressurized
water system
Freshwater system with 60-gallon tank
Freshwater transom shower with hot and cold mixer
Freshwater stainless steel washdown faucet located in anchor locker and cockpit
Generator (low CO gas (7.5 kW) 120V 60 Hz with fire suppression system, automatic with manual override)
Machinery space lighting
Manifold plumbing system with individual valve per circuit
Propellers – stainless steel
Raw-water washdown with stainless steel faucet (located in cockpit)
Shore power inlets (dual 30 amp, isolation transformers and 50ft shore power cords included)
Transducer pocket in hull bottom for flush mounting B260/B275 transducer
Water heater (6 gallons)

Download the full pdf specification sheet here.

Email us for current lead times
