New 350 Realm Hull 2024 Model

3x Mercury L6 350 Verado Engines in Black

Priced from:  £ P.O.A.

The exciting new Realm range is designed to deliver all the open-cockpit versatility of a centre console with the protection and comfort of a cabin cruiser.

First in the series is the 350 Realm – which launched straight into the coveted 2018 Innovation Award recently at the Miami International Boat Show (US National Marine Manufacturers Assn). Whether exploring, entertaining, fishing, diving or just playing about the state-of-the-art navigation and propulsion technology makes the Realm a breeze to operate.

• Full cabin features convertible V-berth and enclosed stand-up head
• Cockpit Prep Center with fridge, sink and grill and massive built-in cooler make the Realm a natural for entertaining
• Conversation flows easily between the robust bow lounge and forward island deck seating
• Available Joystick Piloting system for worry-free docking

Performance …
• Highly efficient Mercury® outboard engines power long-distance journeys
• Precision-engineered hull delivers a soft, safe, dry ride
• Integrated hard-top and easy-up weather curtains provide protection from the elements
• Cockpit dive door and rugged fishing features encourage action-packed recreation






  • LOA: 35’ 6“ (10.82 m)
  • Beam: 10’ 10” (3.30 m)
  • Draft: 24.5” (0.62 m)
  • Weight (with engines, fuel, water and batteries): 18,830 lbs (8,559 kg)
  • Maximum Weight Capacity: 4,670 lbs (2,118 kg)
  • Swamped Capacity: 4,000 lbs (1,814 kg)
  • Maximum Persons Capacity: 14
  • Maximum Horsepower: 1,050 HP (783 kW)
  • Minimum Horsepower: 750 HP (559 kW)
  • Maximum Engine Weight: 2,100 lbs (953 kg)
  • Transom Height: 30” (0.8 m)
  • Transom Angle: 15º
  • Deadrise at Transom: 23º
  • Fuel Capacity: 385 gallons (1,457 L)
  • Waste Capacity: 10 gallons (38 L)
  • Water Capacity: 45 gallons (170.34 L)
  • Bridge Clearance with Top: 8’ 10” (2.70 m)
  • Bridge Clearance with Top and Radar: 9’ 11” (3.02 m)

All hardware 316-L stainless steel
All rails welded 316-L stainless steel

10” stainless steel cleats – stern cockpit with gunnel board hawse pipe (2), anchor locker (1)
10” stainless steel pull-up cleats – bow (2), midship spring line (2), crosstie cleats at transom (2)
28” interior freeboard
Acrylic transom door with stainless steel latch
Bow eye
Drink holders (stainless steel) – bow (8), helm(2), prep station (3), forward console lounge (3),cockpit gunnel boards (1)
Integral swim platform with recessed telescoping
dive ladder and grab rail
Full coaming bolsters
Lighting – blue and white LED courtesy lighting(cockpit)
Lighting – machinery space LED lighting
Molded fiberglass port side dive/boarding door with removable stainless steel dive ladder
Pressurized livewell (15 gallons) in aft port corner with clear lid and blue interior with red
LED lights
Rails – bow rail (low profile interior)(welded stainless steel)
Rails – heavy duty white rub rail with stainless steel insert
Rod holders (gunnel mounted) – starboard cockpit (2), port cockpit (2) Rod holders (transom)(3)
Self-bailing cockpit sole
Thru hull anchor roller davit (stainless steel)
Windlass – 400’ of rode and chain with
handheld remote control, stainless steel swivel, galvanized steel anchor (35 lbs) and polished stainless steel bow roller

Center helm layout
Dash visor with custom stitched cover and recessed storage tray with USB and 12-V charging receptacles
Drink holders (3)
Electronics mounting surface with space for dual displays
Electrical system switch panel with illuminated text
Ignition switches – remote key switches in main DC panel cabinet with pushbutton start/stop at helm
Lockable acrylic sliding cabin entry door
Mercury® DTS dual binnacle controls featuring Shadow Mode for center engine with integrated engine trim controls
Mercury® SmartCraft Vessel View Display
7” color LCD display (network connections to Raymarine with Navigation Package)(located on hardtop)
Molded console footrests and fold-down helm standing platform with maintenance free, anti-fatigue synthetic surface providing
improved visibility and comfort for the captain
Steering wheel (cast stainless steel with urethane grip, speed knob and tilt)
Stereo – Fusion® MS-BB300 (integrated into Raymarine with navigation package) –includes: Fusion Black Box stereo, AM/FM/
VHF/MP3, USB Aux input, iPod/iPhone/Android compatible via integrated Bluetooth, Sirius XM option ready, stereo remote controls with LCD display providing full audio control from the cabin, helm and bow, JL Audio waterproof speakers (exterior, 6.5”
aft cockpit (2), 7.7” at helm deck (2), 7.7” at bow (2), 10” sub-woofer at helm deck (1),6.5” in cabin (2) with JL Audio amplifiers)

Foldout stern bench seat
Bow lounge with backrest and fold-down armrests with integrated drink holders (3)
Bow wrap-around seating with drink holders (4), full height forward bolster and removable cushions
Deluxe swivel 2-person helm seat with armrests (adjustable electric slide and 180-degree rotation creating an apposed seating conversation and dining area)
Helm deck second row with 2-person seat with a conversation seatback transforming to an aft facing seat with flip-down teak foot rests

Bow anchor locker with drains and LED lighting
Cabin – starboard side storage cabinet
Canvas or lifejacket storage cabinet
Drawer storage in helm deck prep station
Forward coaming pockets
Head storage compartment (under vanity)
Insulated 230qt built-in cooler/storage under second row seating
Insulated 26qt cooler tub in starboard helm deck counter
Insulated in-floor fishboxes with pump-out – aft (2)
Lockable electronics box in hardtop
Storage cabinet under starboard helm deck counter
Storage under bow seat with LED lighting

Hardtop frame – custom powder-coated aluminum frame integrated into the deck providing unobstructed walkways
Canvas enclosure or lifejacket storage
Windshield defogger system (integrated into the hardtop)
Ladder access to hardtop
Lighting (flood light) – recessed LED lighting for bow area (1)
Lighting (flood lights) – recessed LED lighting for cockpit area (2)
Lighting – red/white LED courtesy map light (1)
Lighting – blue/white LED overhead courtesy lighting(6)
Lighting – LED navigation lights recessed in the hardtop
Lockable electronics box with 12V receptacle
Outrigger ready
Tempered glass windshield with power actuated vent
Windshield wiper with intermittent control and wash system

120V GFI outlet
Drink holders (3)
Electric grill with solid surface cover with custom popup rotation providing a prep counter while grilling
Freshwater sink with hot and cold
Grab rail – stainless steel
Helm deck second row 2-person seat with conversion seatback transforming to an aft facing seat with flip down teak foot rests
Insulated 230qt built-in cooler/storage under second row seating with dual access
Pullout teak footrest on the forward and aft sides of the second-row seating
Refrigerator – stainless steel (12V/120V)(2.3 cubic ft.)
Storage drawers

28” flat screen HDTV (with Apple TV, integrated with included iPad)
Digital Vessel Control and Information – iPad with inductive wireless charging case (custom app to wirelessly monitor and control some vessel systems and DC circuits)
Opposing seating that converts to berth
LED overhead lights with dimmer switches (6)
LED blue/white diffused courtesy lighting with dimmer switch
Easy to clean interior materials
Opening portholes with screens (2)
Hardwood cabin sole
Lockable acrylic cabin door
Portside window
120V receptacle (starboard side)
12V receptacle
USB power receptacle – dual inputs (port and starboard)
Carbon monoxide detector

120V outlet
500 GPH shower sump
Accent wall
Flooring – solid surface tile
Full length mirror
LED overhead lighting
Pullout showerhead with mixer valve and vertical adjustment
Seat – teak flip up seat over toilet
Shower curtain
Sink – molded fiberglass sink with hot and cold faucet
Solid surface vanity countertop
Storage teak shelf
Toilet paper holder
VacuFlush™ toilet, holding tank, dockside pump-out, overboard discharge and tank level indicator
Vanity grab rail
Vanity storage

300L6 DTS Triple Black Mercury Verado FourStroke engines with hydraulic power steering and Shadow Mode technology (91 octane fuel recommended)
400-gallon aluminum fuel tank
Advanced battery management system (electric switches with pushbutton paralleling)
Air conditioner (cabin)(12,000 BTU, reverse cycle)
Air conditioner (cockpit)(18,000 BTU, reverse cycle)
Battery charger (50 AMP at 12V multi-stage charger)
Battery trays
Bilge pump – high water pump with alarm (2000 GPH aft)
Bilge pump – automatic (1100 GPH fwd, 2000 GPH aft)
Bonding system for underwater through hull fittings
Bow thruster (12V – 4kW)(not available with Joystick Piloting engine options)
Cast bronze thru hulls, seacocks and sea strainers (below waterline)
Cast stainless steel thru hulls (above waterline)
Electric dual trumpet horn
Electric trim tabs with indicator (Auto Glide, Dynamic Running Surface, dual ram)
Engine fuel / water separators with large canisters (not using WIF sensor)
Freshwater dive door shower with hot and cold mixer located in prep station
Freshwater dockside hookup and tank level indicator integrated into Digital Monitoring System for hot and cold pressurized water system with 45-gallon tank
Freshwater manifold plumbing system with individual valve per circuit
Freshwater transom shower with hot and cold mixer
Freshwater stainless steel washdown faucet located in anchor locker and cockpit
Generator (low CO gas (7.5 kW) 120V 60 Hz with fire suppression system, automatic with manual override)
Livewell – pressurized (15-gallon) with clear top window and blue interior (with red LED light) in aft port corner
Machinery space lighting (4)
