STANDARD EQUIPMENT

All hardware 316-L stainless steel
All rails welded 316-L stainless steel

DECK / COCKPIT

• 10″ stainless steel cleats (stern cockpit with gunnel board hawse pipe (2), anchor locker (1)
• 10″ stainless steel pull-up cleats (bow (2), spring line (2), crosstie cleats at transom (2)
• 28″ interior freeboard
• Acrylic transom door with stainless steel latch
• Anchor roller davit – stainless steel thru hull
• Boarding ladder at transom
• Bow tow eye – heavy duty polished stainless steel
• Chrome Boston Whaler logo/model designator
• Drink holders – stainless steel (4 in bow, 2 in hawse pipes, 6 at helm, 2 at console
lounge, 2 at leaning post)
• Full coaming bolsters
• Lighting – LED courtesy lighting in cockpit (Blue)
• Livewell – pressurized insulated (24-gallons) in aft port corner with clear lid, Blue
interior and Red LED light
• Molded fiberglass boarding/dive door port side with removable stainless steel dive
ladder with dedicated storage
• Rails – cockpit toe rails – stainless steel
• Rails – handrails; companion way, boarding ladders, prep station – welded stainless steel
• Rails – low profile interior bow rails – welded stainless steel
• Rod holders – gunnel mounted (bow (4), aft cockpit starboard (4), port (2)
• Rod holders – transom mounted (5)
• Rod holders – under gunnel (3) S
• Rub rail – White with stainless steel inserts
• Self-bailing cockpit sole
• Ship’s bell
• Under gunnel storage shelf with downrigger weight holders (2 per side)
• Windlass with 400′ rode and chain with handheld remote-control, stainless-steel swivel
and polished stainless-steel anchor (44 lbs)

HELM CONSOLE

• A/C vents (2)
• Center helm layout
• Compass
• Dash visor
• Drink holders (2)
• Electrical switch panel with stainless steel switches with illuminated text
• Electronics mounting surface with space for triple 15″ displays
• Footrest – port side passenger fold-down footrest
• Footrest molded into console with fold-down standing platform and maintenance free,
anti-fatigue synthetic surface
• Lockable acrylic sliding entry door, lockable glove box with 12 V receptacles and USB
charging port
• Mercury® DTS dual binnacle controls with integrated engine trim controls
• Rails – grab rail – stainless steel
• 19″ Simrad® NSO evo3S Electronics / Dual Navigation Package – Dash surface – custom
black acrylic integrated with switch panels and flush mounting of dual displays,
Simrad NSO evo3S 19″ screen (GPS, Chart Plotter, Fishfinder), Simrad NSO evo3S 19″
screen (Additional Display), Active Imaging 3 in 1 Transom Mount Transducer (CHIRP,
SideScan, DownScan), Integrated Mercury® VesselView® Link and Simrad RS40 VHF
Radio with AIS and HS40 wireless handset
• Steering wheel – cast stainless steel with knob and tilt helm
• Switches – remote ignition key switches in cabin with pushbutton start/stop at helm
• Windshield defogger with remote shutoff control

OPEN WINDSHIELD HARDTOP SYSTEM

• Custom powder coated frame integrated into the deck providing clean
unobstructed walkways (White or Black depending on frame color selection)
• Electronics box with locking latch above helm
• Ladder access to hardtop integrated into hardtop frame, port side
• Lighting – LED flood lights bow (1), cockpit (2)
• Lighting – LED navigation lights
• Lighting – LED overhead courtesy/chart light (Red and White)
• Lighting – LED overhead lighting (Blue)
• Open tempered side glass with upper removable rigid acrylic canvas curtain
• Outrigger ready
• Rod holders integrated onto hardtop supports (6) (White or Black depending on frame
color selection)
• Sunshade for cockpit – telescoping polished stainless-steel frame retracts and deploys
electrically (Black/Tan Sunbrella® canvas depending on canvas color selection)
• Windshield – full tempered glass, full height with electric actuated center vent
• Windshield wipers – (1) stainless steel pantograph with wash-system

DELUXE LEANING POST / BAIT PREP CENTER

• 120 V outlets (2)
• Bait prep area with cutting board
• Drink holders (2)
• Electric grill with hinged solid surface lid over grill providing counter surface when not
in use
• Freshwater sink with hot and cold water
• Leaning post cushion on forward side of prep-station that also converts to a 3-person
bench seat providing a second row of seating
• Lighting – LED task lighting
• Livewell – (insulated 40-gallons) pressurized with viewing window, clear lid, Blue
interior, and Red LED light
• Pump switch panel with 12 V outlet
• Rail – grab rail – stainless steel
• Refrigerator – stainless steel drawer 12 V / 120 V (2.3 cubic ft) (starboard side)
• Solid surface countertop
• Storage lid with tool holders, storage nets and leader holders
• Tackle storage drawers (3) (port side)

SEATING EXTERIOR

• Flip-up backrest at forward end of lounge providing wraparound seating
• Fold-away stern bench seat
• Forward console lounge with fold-down armrests, drink holders (4), backrests and
removable cushion
• Forward port and starboard seats with folding backrests and drink holders (4) with
stereo remote and 12 V receptacle on port side
• Helm and companion bolster style seats (3) with fold-down armrests (center seat is
electrically actuated) (port and starboard seats rotate to face aft)
• Leaning post cushion on forward side of the prep station that also converts to 3-person
bench seat providing a second row of seating behind the helm

STORAGE EXTERIOR

• Bilge storage aft
• Bow anchor locker with drains
• Coaming storage pockets with acrylic doors in port and starboard fore deck area (4)
• Coaming storage pockets with net retainers in port and starboard helm deck area (4)
• Forward lounge storage – miscellaneous gear, fender storage or optional dive tank storage
• Insulated built-in storage/cooler compartment at forward end of the console lounge
• Insulated in-floor fishboxes with drains, helm deck (2)
• Insulated in-floor storage/fishbox with drains, fore deck (2)
• Insulated in-floor storage/fishboxes with pump-out, cockpit (2)
• Lifejacket or weather curtain storage in overhead hardtop storage compartment
• Lighting – LED lighting in storage compartments
• Lockable electronics box in hardtop
• Lockable glove box
• Prep station side pockets (2)
• Prep station storage drawers
• Storage under bow seating

STORAGE INTERIOR

• Companionway hanging locker
• Galley – cabinet aft of microwave
• Galley – hinged lid integrated into countertop providing access to storage compartment
• Galley – pull-out waste receptacle and dish storage
• Head cabinetry
• Storage under interior seating

CABIN INTERIOR

• 120 V receptacle – port side
• 12 V USB charging ports – port and starboard sides
• 28″ flat screen HDTV
• Air conditioner (12,000 BTU)
• Carbon monoxide detector
• Central vacuum system with hose and attachments with dedicated storage
• Console side windows with (2) opening port lights with shades
• Convertible double berth with filler cushion; comes with fitted sheet, comforter and two
regular size pillowcases
• Convertible pull-out settee
• Digital vessel control; iPad with inductive charging case, CZone® App (monitor vessel
systems and control DC circuits)
• Easy to clean interior materials
• Elite Interior Color and Material Package
• Hanging locker
• Hardwood cabin sole
• Hull side windows with shades
• Lighting – LED diffused courtesy lights (Blue)
• Lighting – LED diffused overhead lights (White)
• Lighting – LED reading lights (2)
• Rod storage (4)
• Skylight with integrated shade system
• Stereo System (JL Audio integration into Simrad Navigation Package), HELM: JL Audio
MM105-HR stereo with Dash mounted remote volume/mute knob, AM/FM/HD Radio,
USB audio, and Sirius XM® ready, iPhone®/Android® compatible via integrated Bluetooth®
5.0. BOW: JL Audio MMR-40 Stereo Remote, JL Audio waterproof speakers (8), 10″
Subwoofer (2), and 600W & 800W Amplifier. CABIN: JL Audio MMR-40 Stereo Remote
and JL Audio speakers 6.5″ (4)
• Table – wood table that lowers to support filler cushion for forward double berth
• Throw pillows (3)

GALLEY

• 120 V receptacle
• 12 V receptacle
• Dedicated dish storage in pull-out drawer below sink and in a cabinet above the sink
• Microwave
• Pull-out waste receptacle
• Rail – handrail – stainless steel
• Refrigerator/freezer – stainless steel 12 V / 120 V (1.7 cubic ft)
• Sink filler – solid surface matching countertop with integral cutting board
• Sink with faucet and solid surface countertop

ENCLOSED HEAD COMPARTMENT
• Accent wall
• Electric VacuFlush® toilet, holding tank with vent filter, overboard discharge, dockside
pump-out and tank level indicator
• Enclosed shower – rain shower head with hot and cold faucet and shower curtain
providing protection of vanity area
• Flooring – solid surface tile
• Lighting – LED overhead light
• Mirror
• Opening port light
• Rail – handrail – stainless steel
• Shower sump
• Solid surface pull-out countertop forward of vanity
• Toilet paper holder
• Vanity storage
• Vanity with sink, polished chrome faucet and backlit mirror
